PREVIEW AND ANALYZE IN 3D BEFORE YOU BUILD

3D STEP MODELS

Download components for free in over 30 CAD formats. Models are available for download on Ultra Librarian, or from participating distributors, manufacturers, or PCB design tools.

Design in your preferred CAD tool or through our available apps and integrations. Get back to what matters most; innovation, not part creation.

Accurate components for your PCB Parts

3d step models

Finding 3D models for the components in your PCB can be a daunting task. Even if models exist they may not be in formats your PCB tool can accept or are not in synch with your existing PCB footprints requiring manual orientation and checking.

Prevent fit errors, perform early thermal analysis, and view your design in realistic 3D before a single prototype is built with 3D models from Ultra Librarian. Examples of 3D models available for download include:

Bel Fuse Inc. Fuse Clips: FC -203 BRIGHT TIN

Diodes Inc. Standard Diode: 1N4148W-7-F

Fairchild Semiconductor Regulator: LM7805CT

Stackpole Inc. Carbon Film Resistors: CF14JT10K0

Texas Instruments Bipolar Array Transistor: ULN2803ADWR

FIND PARTS FROM OVER 2,500 MANUFACTURERS

BROWSE PARTS FROM YOUR FAVORITE MANUFACTURERS

Check out all manufacturers here.
